Chemical composition % MAX
THICKNESS(MM)	C	Mn	Si	P	S	N	Cu
≦40	0.17	1.4	~	0.03	0.03	0.012	0.55
>40	0.17
Mechanical properties MIN
	Yield Strength MPa		Tensile Strength MPa		Elongation in 2 in. %
≦16	235		360-510		17
>16,  ≦100	225
>100	175		340-500

Chemical composition % MAX
THICKNESS(MM)	C	Mn	Si	P	S	N	Cu
≦40	0.17	1.4	~	0.035	0.035	0.012	0.55
>40	0.20
Mechanical properties MIN
	Yield Strength MPa		Tensile Strength MPa		Elongation in 2 in. %
≦16	235		360-510		17
>16,  ≦100	215
>100	175		340-500

Chemical composition % MAX
THICKNESS(MM)	C	Mn	Si	P	S	N	Cu
≦40	0.21	1.5	~	0.035	0.035	0.012	0.55
>40	0.22
Mechanical properties MIN
	Yield Strength MPa		Tensile Strength MPa		Elongation in 2 in. %
≦16	275		410-580		15
>16,  ≦100	235
>100	205		380-540

Chemical composition % MAX
THICKNESS(MM)	C	Mn	Si	P	S	N	Cu
≦40	0.17	1.4	~	0.025	0.025	~	0.55
>40	0.17
Mechanical properties MIN
	Yield Strength MPa		Tensile Strength MPa		Elongation in 2 in. %
≦16	235		360-510		15
>16,  ≦100	225
>100	165		330-510

Chemical composition % MAX
THICKNESS(MM)	C	Mn	Si	P	S	N	Cu
≦40	0.18	1.5	~	0.025	0.025	0.012	0.55
>40	0.18
Mechanical properties MIN
	Yield Strength MPa		Tensile Strength MPa		Elongation in 2 in. %
≦16	275		410-580		13
>16,  ≦100	235
>100	195		410-580

Chemical composition % MAX
THICKNESS(MM)	C	Mn	Si	P	S	N	Cu
≦40	0.18	1.5	~	0.03	0.03	0.012	0.55
>40	0.18
Mechanical properties MIN
	Yield Strength MPa		Tensile Strength MPa		Elongation in 2 in. %
≦16	275		410-580		15
>16,  ≦100	235
>100	205		380-540



Chemical composition % MAX
THICKNESS(MM)	C	Mn	Si	P	S	N	Cu
≦40	0.20	1.6	0.55	0.03	0.03	0.012	0.55
>40	0.22
Mechanical properties MIN
	Yield Strength MPa		Tensile Strength MPa		Elongation in 2 in. %
≦16	355		470-680		14
>16,  ≦100	315
>100	275		450-600



Chemical composition % MAX
THICKNESS(MM)	C	Mn	Si	P	S	N	Cu
≦40	0.24	1.6	0.55	0.035	0.035	0.012	0.55
>40	0.24
Mechanical properties MIN
	Yield Strength MPa		Tensile Strength MPa		Elongation in 2 in. %
≦16	355		470-680		14
>16,  ≦100	315
>100	275		450-600



Chemical composition % MAX
THICKNESS(MM)	C	Mn	Si	P	S	N	Cu
≦40	0.20	1.6	0.55	0.025	0.025	~	0.55
>40	0.22
Mechanical properties MIN
	Yield Strength MPa		Tensile Strength MPa		Elongation in 2 in. %
≦16	355		470-680		12
>16,  ≦100	315
>100	265		450-600



Chemical composition % MAX
THICKNESS(MM)	C	Mn	Si	P	S	N	Cu
≦40	0.20	1.6	0.55	0.025	0.025	~	0.55
>40	0.22
Mechanical properties MIN
	Yield Strength MPa		Tensile Strength MPa		Elongation in 2 in. %
≦16	355		470-680		14
>16,  ≦100	315
>100	265		450-600



Chemical composition % MAX
THICKNESS(MM)	C	Mn	Si	P	S	N	Cu
≦40	0.20	1.7	0.55	0.03	0.03	0.025	0.55
>40	0.22
Mechanical properties MIN
	Yield Strength MPa		Tensile Strength MPa		Elongation in 2 in. %
≦16	450		550-720		17
>16,  ≦100	410
>100	380		530-700

Bảng Quy Cách Thép Tấm

STT	BẢNG QUY CÁCH THÉP TẤM
	Thép tấm	Dày(mm)	Chiều rộng(m)	Chiều dài (m)
1	Thép tấm	3	1500 – 2000	6000 – 12.000
2	Thép tấm	4	1500 – 2000	6000 – 12.000
3	Thép tấm	5	1500 – 2000	6000 – 12.000
4	Thép tấm	6	1500 – 2000	6000 – 12.000
5	Thép tấm	8	1500 – 2000	6000 – 12.000
6	Thép tấm	9	1500 – 2000	6000 – 12.000
7	Thép tấm	10	1500 – 2000 – 3000	6000 – 12.000
8	Thép tấm	12	1500 – 2000 – 3000	6000 – 12.000
9	Thép tấm	13	1500 – 2000 – 3000	6000 – 12.000
10	Thép tấm	14	1500 – 2000 – 3000	6000 – 12.000
11	Thép tấm	15	1500 – 2000 – 3000	6000 – 12.000
12	Thép tấm	16	1500 – 2000 – 3000	6000 – 12.000
13	Thép tấm	18	1500 – 2000 – 3000	6000 – 12.000
14	Thép tấm	20	1500 – 2000 – 3000	6000 – 12.000
15	Thép tấm	22	1500 – 2000 – 3000	6000 – 12.000
16	Thép tấm	24	1500 – 2000 – 3000	6000 – 12.000
17	Thép tấm	25	1500 – 2000 – 3000	6000 – 12.000
18	Thép tấm	28	1500 – 2000 – 3000	6000 – 12.000
19	Thép tấm	30	1500 – 2000 – 3000	6000 – 12.000
20	Thép tấm	32	1500 – 2000 – 3000	6000 – 12.000
21	Thép tấm	34	1500 – 2000 – 3000	6000 – 12.000
22	Thép tấm	35	1500 – 2000 – 3000	6000 – 12.000
23	Thép tấm	36	1500 – 2000 – 3000	6000 – 12.000
24	Thép tấm	38	1500 – 2000 – 3000	6000 – 12.000
25	Thép tấm	40	1500 – 2000 – 3000	6000 – 12.000
26	Thép tấm	44	1500 – 2000 – 3000	6000 – 12.000
27	Thép tấm	45	1500 – 2000 – 3000	6000 – 12.000
28	Thép tấm	50	1500 – 2000 – 3000	6000 – 12.000
29	Thép tấm	55	1500 – 2000 – 3000	6000 – 12.000
30	Thép tấm	60	1500 – 2000 – 3000	6000 – 12.000
31	Thép tấm	65	1500 – 2000 – 3000	6000 – 12.000
32	Thép tấm	70	1500 – 2000 – 3000	6000 – 12.000
33	Thép tấm	75	1500 – 2000 – 3000	6000 – 12.000
34	Thép tấm	80	1500 – 2000 – 3000	6000 – 12.000
35	Thép tấm	82	1500 – 2000 – 3000	6000 – 12.000
36	Thép tấm	85	1500 – 2000 – 3000	6000 – 12.000
37	Thép tấm	90	1500 – 2000 – 3000	6000 – 12.000
38	Thép tấm	95	1500 – 2000 – 3000	6000 – 12.000
39	Thép tấm	100	1500 – 2000 – 3000	6000 – 12.000
40	Thép tấm	110	1500 – 2000 – 3000	6000 – 12.000
41	Thép tấm	120	1500 – 2000 – 3000	6000 – 12.000
42	Thép tấm	150	1500 – 2000 – 3000	6000 – 12.000
43	Thép tấm	180	1500 – 2000 – 3000	6000 – 12.000
44	Thép tấm	200	1500 – 2000 – 3000	6000 – 12.000
45	Thép tấm	220	1500 – 2000 – 3000	6000 – 12.000
46	Thép tấm	250	1500 – 2000 – 3000	6000 – 12.000
47	Thép tấm	260	1500 – 2000 – 3000	6000 – 12.000
48	Thép tấm	270	1500 – 2000 – 3000	6000 – 12.000
49	Thép tấm	280	1500 – 2000 – 3000	6000 – 12.000
50	Thép tấm	300	1500 – 2000 – 3000	6000 – 12.000
